SOULTER MAXIARC 320
LT DC INVERTER MMA Welding Machine
Features: –
·
TIG Mode: Capable of welding with lift TIG mode.
·
Heavy Industrial Use, Heavy Duty Cycle
·
Extra Functions: Hot Start, ARC Force
adjustable, VRD Selectable, Anti-Sticking built in.
·
Protections: Equipped with temperature, voltage
and current sensors for high protection.
·
Digital display: Variable amperage control with
digital meter with a simultaneous welding current display.
·
Generator Friendly: Designed to work with diesel
generators and to avoid failures due to its voltage spikes.
·
3 Phase 380V/400V 415V/440V 50Hz/60Hz
·
Protec 550V: 550V tested in production
·
Cellulosic Electrode
·
Zero voltage switch
·
Phase loss protection
·
MCU control system
·
IGBT Module
Technical Data: –
| Model | MAXIARC 320 LT |
| Power Supply Voltage |
3 – 400V |
| Effective Current |
TIG/MMA 15/18 |
| Rated Input Power KW |
TIG/MMA 8.5/11.5 |
| Rated Input Current A |
TIG/MMA 19/23 |
| Duty Cycle 40C 10Min |
60% 320A 100% 250A |
| No Load Voltage V |
MMA TIG 60/22.5 |
| Welding Current range, A |
10-320A |
| Net Weight |
17.6KG |
| Dimensions | 485x240x445mm |
| Electrode Diameter |
1.6-6.0 |
| Electrode Type |
6013, 7018 Etc. |
Parameters: –
·
Insulation class: H
·
Power Factory: 0.7
·
Frequency: 50/60Hz
·
Protection Class: IP23
·
Efficiency: > 80%
·
Cooling: AF
Buy the SOULTER MAXIARC 320 LT DC INVERTER MMA Welding Machine in Abu Dhabi, UAE from Tiny Royal General Trading — a trusted and leading material supplier in the UAE.
