Features: –
- Superior Arc characteristics – Smooth, Stable
performance. - Generator Compliant – Suitable for use with
generators (recommended 7 kW). - Easy to Use – Set the welding current and weld with
excellent result - Practical Design – makes the power source easy to
carry which enables use at almost any work site - Robust Design – IP23S Designed for Fabrication
Shop or Site application. - PFC ensures a stable arc, resistant to power
fluctuations even while working on long extension
cables up to 100 m (PRO version only).
Technical Data: –
| Model | ES 200i PRO |
| Primary Voltage 1 ph | 115/230 VAC ±15%, 1ph, 50/60 Hz |
| Maximum Output | 200 A |
| Rated kVA | 6.9 kVA |
| Energy Save Mode | 50 W |
| Open Circuit Voltage | 78 V DC |
|
MMA Welding Output at 20% Duty Cycle at 25% Duty Cycle at 60% Duty Cycle at 100% Duty Cycle |
– 200 A / 28.0 V 129 A / 25.2 V 100 A / 24.0 V |
|
TIG Welding Output at 25% Duty Cycle at 60% Duty Cycle at 100% Duty Cycle |
200 A / 18.0 V 129 A / 15.2 V 100 A / 14.0 V |
| Current Range | 10 –200 A |
| Operating Temperature | -10 to+40 °C |
| Enclosure Class | IP23S |
| Dimensions | 403 x 153 x 264 mm |
| Weight | 8.4 kg |
Buy the ESAB Rogue ES 200i 200Amps MMA/ LIFT TIG Welding Machine in Abu Dhabi, UAE from Tiny Royal General Trading — a trusted and leading material supplier in the UAE.
